    Shinson Technology S425M44SBB

    Shinson Technology S425M44SBB

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17237
    • Container price: $70.20 USD
    • Container qty: 720
    • Pallet price: $3.32 USD
    • Pallet qty: 30
    • Unit price: $0.13 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S425M44SBB Product Warranty 25 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 425 Wp Voltage at Maximum Power (Vmpp) 34.6 V Current at Maximum Power (Impp) 12.3 A Open Circuit Voltage (Voc) 41.7 V Short Circuit Current (Isc) 13.03 A Panel Efficiency 21.4 % Maximum Power (Pmax) 320 Wp Voltage at Maximum Power (Vmpp) 33 V Current at Maximum Power (Impp) 9.7 A Open Circuit Voltage (Voc) 39.8 V Short Circuit Current (Isc) 10.5 A Temperature 42.3±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.27 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1812x1096x30 mm Weight 20.8 kg Cell Number 305 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Power Range: 415 ~ 430 Wp
      Panel Efficiency: 20.9 ~ 21.7 %
      Weight: 20.8 kg
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
