    Shinson Technology S695M66NT4BF

    Shinson Technology S695M66NT4BF

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17284
    • Container price: $43.20 USD
    • Container qty: 720
    • Pallet price: $2.04 USD
    • Pallet qty: 30
    • Unit price: $0.08 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S695M66NT4BF Product Warranty 30 Years Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 695 Wp Voltage at Maximum Power (Vmpp) 39.13 V Current at Maximum Power (Impp) 17.76 A Open Circuit Voltage (Voc) 47.07 V Short Circuit Current (Isc) 18.84 A Panel Efficiency 22.37 % Maximum Power (Pmax) 525 Wp Voltage at Maximum Power (Vmpp) 36.74 V Current at Maximum Power (Impp) 14.29 A Open Circuit Voltage (Voc) 44.94 V Short Circuit Current (Isc) 15.17 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.31 %/°C Temperature Coefficient of Voc -0.26 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2384x1303x35 mm Weight 38 kg Cell Number 132 Glass Type Anti-reflection Coating Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: Bifacial, TOPCon, N-type
      Power Range: 680 ~ 700 Wp
      Panel Efficiency: 21.89 ~ 22.53 %
      Weight: 38 kg
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
