Solar N Plus 595
Solar N Plus 595
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-17696
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. 595 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 595 Wp Voltage at Maximum Power (Vmpp) 45.75 V Current at Maximum Power (Impp) 13.01 A Open Circuit Voltage (Voc) 53.2 V Short Circuit Current (Isc) 13.72 A Panel Efficiency 23 % Maximum Power (Pmax) 449 Wp Voltage at Maximum Power (Vmpp) 42.08 V Current at Maximum Power (Impp) 10.67 A Open Circuit Voltage (Voc) 50.33 V Short Circuit Current (Isc) 11.06 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1134x30 mm Weight 31.5 kg Cell Number 144 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon
Power Range: 570 ~ 600 Wp
Panel Efficiency: 22.1 ~ 23.2 %
Weight: 31.5 kg
Seller: Solar N Plus New Energy Tech. Co., Ltd
Country: China -
