Out of Stock
Solar N Plus 650
Solar N Plus 650
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-17702
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. 650 Product Warranty 12 Years Power Warranty 30 Years of 84.95 % Total Degradation Rate ⏳ 0.5 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 650 Wp Voltage at Maximum Power (Vmpp) 37.4 V Current at Maximum Power (Impp) 17.38 A Open Circuit Voltage (Voc) 45.2 V Short Circuit Current (Isc) 18.46 A Panel Efficiency 20.9 % Maximum Power (Pmax) 492 Wp Voltage at Maximum Power (Vmpp) 34.9 V Current at Maximum Power (Impp) 14.09 A Open Circuit Voltage (Voc) 42.6 V Short Circuit Current (Isc) 14.85 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2385x1303x30 mm Weight 38.7 kg Cell Size 210×210 mm Cell Number 132 Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 645 ~ 675 Wp
Panel Efficiency: 20.7 ~ 21.7 %
Weight: 38.7 kg
Seller: Solar N Plus New Energy Tech. Co., Ltd
Country: China -
