    Techwise Solar 565W

    Techwise Solar 565W

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-20715
    • Container price: $43.20 USD
    • Container qty: 720
    • Pallet price: $2.04 USD
    • Pallet qty: 30
    • Unit price: $0.08 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. 565W Product Warranty 15 Years Power Warranty 15 Years of 93.40 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 565 Wp Voltage at Maximum Power (Vmpp) 43.58 V Current at Maximum Power (Impp) 12.99 A Open Circuit Voltage (Voc) 51.63 V Short Circuit Current (Isc) 13.58 A Panel Efficiency 21.86 % Maximum Power (Pmax) 426 Wp Voltage at Maximum Power (Vmpp) 39.63 V Current at Maximum Power (Impp) 10.75 A Open Circuit Voltage (Voc) 48.34 V Short Circuit Current (Isc) 11.46 A Temperature 44±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2278x1134x30 mm Weight 32 kg Cell Size 182×91 mm Cell Number 144 Glass Thickness 2 mm Frame Type Anodized Aluminium Junction Box Diodes 4 Junction Box Protection Class IP 68 Conn

      Technology: Bifacial, TOPCon, N-type
      Power Range: 560 ~ 580 Wp
      Panel Efficiency: 21.67 ~ 22.44 %
      Weight: 32 kg
      Seller Name: Techwise Solar Technology Co., Ltd.
      Country: China
