Ulica Solar UL-455M-108BDGN
Ulica Solar UL-455M-108BDGN
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-21868
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. UL-455M-108BDGN Product Warranty 15 Years Power Warranty 15 Years of 93.05 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 455 Wp Voltage at Maximum Power (Vmpp) 33.42 V Current at Maximum Power (Impp) 13.61 A Open Circuit Voltage (Voc) 39.98 V Short Circuit Current (Isc) 14.45 A Panel Efficiency 22.77 % Maximum Power (Pmax) 345 Wp Voltage at Maximum Power (Vmpp) 30.75 V Current at Maximum Power (Impp) 11.21 A Open Circuit Voltage (Voc) 36.38 V Short Circuit Current (Isc) 11.34 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1762x1134x30 mm Weight 24 kg Cell Size 182.2×94 mm Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1100 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, N-type
Power Range: 445 ~ 460 Wp
Panel Efficiency: 22.27 ~ 23.02 %
Weight: 24 kg
Seller: Ningbo Ulica Solar Co., Ltd.
Country: China -
