Ulica Solar UL-475M-108HVN
Ulica Solar UL-475M-108HVN
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-21872
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. UL-475M-108HVN Product Warranty 15 Years Power Warranty 15 Years of 90 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 475 Wp Voltage at Maximum Power (Vmpp) 33.82 V Current at Maximum Power (Impp) 14.04 A Open Circuit Voltage (Voc) 40.38 V Short Circuit Current (Isc) 14.89 A Panel Efficiency 23.27 % Maximum Power (Pmax) 360 Wp Voltage at Maximum Power (Vmpp) 31.11 V Current at Maximum Power (Impp) 11.57 A Open Circuit Voltage (Voc) 36.75 V Short Circuit Current (Isc) 12.01 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1800x1134x30 mm Weight 21.5 kg Cell Size 182.2×95.8 mm Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1100 mm Download Manufacturer's PDF Datasheet
Technology: TOPCon
Power Range: 465 ~ 475 Wp
Panel Efficiency: 22.78 ~ 23.27 %
Weight: 21.5 kg
Seller: Ningbo Ulica Solar Co., Ltd.
Country: China -
