Victron Phoenix 48/375 VE.Direct NEMA GFCI Pure Sine Wave Inverter - PIN483750510

Victron Phoenix 48/375 VE.Direct NEMA GFCI Pure Sine Wave Inverter - PIN483750510

Regular price $110.87 USD
Regular price Sale price $110.87 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SIV-0246
  • Brands: Victron Energy
  • Documents:
  • Height: 8.6
  • Length: 25.9
  • Width: 16.5
View full details
  • Victron Energy PIN483750510

    Victron Phoenix 48/375 VE.Direct Pure Sine Wave Inverter

    The Victron Phoenix 48/375 VE.Direct Inverter is designed by Victron Energy to provide reliable backup power with optimum efficiency. Its pure sine wave output is ideal for sensitive electronics. With Victron Energy's PIN483750510 model, users benefit from advanced features and robust performance suitable for various applications.

    Product Features

    VE.Direct Communication Port

    Integrate the inverter with computers and smart devices via the VE.Direct port using an appropriate USB cable or Bluetooth Smart dongle, enhancing connectivity and user control.

    Fully Configurable Settings

    Personalize the functionality with options to configure low battery voltage alarms, cut-off and restart levels, offering user-specific flexibility and enhanced system protection.

    Dynamic Load and Output Settings

    Adjustable output voltage and frequency settings ensure the inverter adapts to varying load demands, maintaining performance with load-dependent cut-off features.

    ECO Mode Functionality

    ECO mode intelligently switches the inverter to standby to save energy when load decreases below a threshold, activating again when needed to optimize power consumption.

    High Start-up Power and Reliability

    Proven design with high start-up power capability meets the demands of starting devices like LED converters or electric tools, backed by reliable short circuit and overheating protection.

    How It Works

    This inverter operates using advanced full bridge and toroidal transformer technologies, providing consistent and efficient power conversion for various electronic devices under both light and heavy loads.

    Component Integration

    The system effortlessly transitions between AC sources with the optional Filax Automatic Transfer Switch, ensuring continuous operation for sensitive electronics during power fluctuations.

    Remote Control Optionality

    Convenience is enhanced with a remote on/off switch capability, allowing for easier operational control from varied locations, enhancing user flexibility and adaptability.

    LED Diagnostic Indications

    The integrated LED diagnostic system provides clear status updates and alerts the user to operational changes, helping maintain optimal performance and easy troubleshooting.

    Specifications

    Continuous Power at 25°C 375VA
    Input Voltage Range 36.8 - 62.0V
    Output AC Voltage/Frequency 230VAC or 120VAC ±3%, 50Hz or 60Hz ±0.1%
    Peak Power 700W
    Dynamic DC Low Shut Down 9.3V / 18.6V / 37.2V
    Maximum Efficiency 91%
    Zero-load Power Usage 5.2 / 6.1 / 8.5W
    Operating Temperature Range -40 to +65°C
    Protection Category IP 21
    Dimensions (h x w x d, mm) 86 x 172 x 275
    Weight 3.9kg
